Eurolite Board 10-ST 10x Schutzkontakt 19" power distributor 3 U

A black control panel with ten red switches and labelled 'BOARD 10-ST'. 'euro lite' is written top left. Suitable for lighting control.
'Eurolite Control Panel BOARD 10-ST' with ten red switches and labels CH-1 to CH-10, for lighting or stage technology.
Black control panel with red switches, labelled as 'Eurolite'. Two main functions: 'Switch' and 'Flash'.
'Control panel with 20 red buttons, divided into two rows. Labelled: CH-1 to CH-20, plus two switches for "Switch" and "Flash".'
A black rack module with 12 numbered sockets, labelled from 'CH 1' to 'CH 12'. The module is designed for mounting in a rack.
A black power strip with twelve numbered socket outlets from 'CH 1' to 'CH 12', suitable for electrical connections.
1/6
EAN:
Part number:
Item no:
Dispatches on Fri 30 Oct
46 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 109.99 / piece)
€ 109.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Eurolite Board 10-ST 10 x protective contact

  • 10-switch panel

Technical specifications

  • Power supply: 230 V AC, 50 Hz
  • Max. Total output: 3680 W
  • Max current: 16 A.
  • Max. Current/channel: 5 A
  • Output Sockets: 10 protective contact sockets
  • Fuses: F 6.3 A, 250 V
  • Dimensions (wxdxh): 483 x 125 x 88 mm
  • Weight: 2.8 kg
Product type

19" power distributor

Rack unit

3 U

Inputs

PG plug

Outputs

PG connector

No. of PG sockets

10

Features

Switchable

Width

483 mm

Height

132 mm

Weight

3.29 kg

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 593292 Eurolite Board 10-ST 10x Schutzkontakt 19" power distributor 3 U

Description

10-switch panel · Completely cabled housing with 10 outlets · Cabling to 16 A safety plug · 10 Switch with flash buttons · 10 fuse holder with 5 A
