FESTO Dual piston cylinder 159972 DPZJ-32-50-P-A-S2 Stroke length: 50 mm 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 1,065.00 / piece)
€ 1,065.00
incl. VAT
Only available for business customers
14-day return policy includedHighlights & Details
Dual piston cylinder DPZJ-32-50-P-A-S2
Technical specifications
- Operating medium
According to ISO 8573-1:2010 compressed air [7:4:4]
- Product type
Dual piston cylinder
- Stroke length
50 mm
- Max. operating pressure
10 bar
- Material (details)
Aluminum wrought alloy
- Manufacturer part #
159972
- Type
Double piston-cylinder -32-50 DPZJ-P-A-S2 with two parallel, continuous piston rods and yoke drives, for position detection, with elastic damping rings in the end positions. Hub = 50 mm, adjustable end position range/length = 10 mm, piston diameter = 32 mm, operating mode drive unit = yoke, attenuation=P: elastic damping rings/boards on both sides
- Size
32
- Sealant
NBR
- Pneumatics connector
G1/8"
- Piston rod material
Steel (stainless)
- Piston rod diameter
32 mm
- Force (max.)
724 N
- Max. ambient temperature
+80 °C
- Min. ambient temperature
-20 °C
- Operating principle
Double-acting
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1936794 FESTO Dual piston cylinder 159972 DPZJ-32-50-P-A-S2 Stroke length: 50 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1936794 FESTO Dual piston cylinder 159972 DPZJ-32-50-P-A-S2 Stroke length: 50 mm 1 pc(s)
