FESTO Vacuum cleaner VAS-2-M3-NBR 173438 M3 Nominal width (details) 1 mm Sealant NBR
EAN:
Part number:
Item no:
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 13.99 / piece)
€ 13.99
incl. VAT
Only available for business customers
14-day return policy includedHighlights & Details
Technical specifications
- Tear-off force at 70% vacuum: 0.14 N.
- Connection position: Top
- Fastening thread: M3
- Operating medium: Atmospheric air in accordance with ISO 8573-1:2010 [7:-:-]
- Colour: Black
- Holding force at nominal operating pressure 0.14 N.
- Nominal diameter 1 mm
- Suction unit mounting: M3
- Suction unit diameter 2 mm
- Suction cup shape: Round flat
- Shore hardness 55 +/- 5
- Ambient temperature: -20 ... 80 °C
- Vacuum connection: M3
- Screw-in bolt material: High-alloy steel
- Material suction unit: NBR
- Material note: RoHS compliant
- Effective suction diameter 1.6 mm
- Operating medium
Atmospheric air
- Type
173438
- Product type
Vacuum cleaner
- Connection
M3
- Operating temperature
-20 °C (min)
- Min. operating temperature
-20 °C
- Manufacturer part #
173438
- Sealant
NBR
- Weight
0.5 g
- Medium
Natural air
- Nominal width
1 mm
- Max. ambient temperature
+80 °C
- Min. ambient temperature
-20 °C
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2203724 FESTO Vacuum cleaner VAS-2-M3-NBR 173438 M3 Nominal width (details) 1 mm Sealant NBR
Description
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
