FISCHER FAHRRAD Cycle carrier ProlineEvo 126001 No. of bicycles=2
EAN:
Part number:
Item no:
Number
Total (€ 335.29 / piece)
€ 335.29
plus VAT.
Highlights & Details
ProlineEvo clutch bicycle carrier
- Suitable for e-bikes
- Pre-assembled for easy use
- Lockable
- Suitable for frames up to 6 cm ø
- Foot pedal operation
- Rolls for easy transport
Technical specifications
- Track distance: Approx. 25cm
- Wheel base: Max. 137cm
- Rail type: Detachable wheel holder extension 146cm (110cm)
- Dim
(W x H x D) 70 x 66 x 28 cm
- Distance between bikes
25 cm
- Connector
13-pin
- No. of bicycles
2
- Width (folded)
61 cm
- Features
Folding
Suitable for electric bicycles
- Suitable for frame size (max.)
60 mm
- Weight
14.6 kg
- Height (folded)
28 cm
- Length (folded)
63 cm
- Material
Steel
- Mounting site
Trailer hitch
- Width
70 cm
- Height
66 cm
- Depth
28 cm
- Series
ProlineEvo
- Load capacity
60 kg
- Product type
Cycle carrier
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1672533 FISCHER FAHRRAD Cycle carrier ProlineEvo 126001 No. of bicycles=2
Description
The bicycle carrier is 99% pre-assembled and the installation takes little time. The carrier has a snap closure which is lockable. The frame holders are lockable and the frames up to 6 cm diameter are suitable. The frame bracket can be folded/tilted. The bicycle carrier has a folding mechanism, which can be operated with a foot pedal. The unloaded carrier has integrated rollers for easy transport. The carrier has wide wheel holders with plastic bands including ratchet function. This has a removable wheel holder extension. The distance between the rails is approx. 25cm and the wheelbase is max. 137cm.
This text is machine translated.
This text is machine translated.
Features
- Suitable for e-bikes
- Pre-assembled for easy use
- Lockable frame holder and quick-release fastener
- Suitable for frames up to 6 cm ø
- Folding/tilting frame bracket
- Folding mechanism with foot pedal operation
- Integrated rollers for easy transport
- Wide wheel holder with plastic straps incl. ratchet function
- Detachable wheel holder extension
- Track distance: Approx. 25 cm
- Wheel base: Max. 125 cm
- Folded up approx. 63 x 28x 61 cm
- Max. Payload 60 kg
- Net weight: 15.68 kg.
- Plug: 13-pin (assigned with 9 pins. Sufficient for this carrier)
