Highlights & Details

Insulation tester Fluke 1507

CAT IV 600V

Technical specifications

Measuring Voltage tolerance: ± (10% v.M. such + 3D)

Product type: Insulation tester

Test voltage: 50 V
100 V
250 V
500 V
1000 V

Reading type: Insulation resistance

Continuity testing: acoustic (test current 200 mA)

: Manufacturer's standards (no certificate)

Reading range - resistance: 0.01 Ω - 20 kΩ

Interfaces: none

: IP40

Power supply (details): 4 x AA batteries

Dim: (W x H) 10 cm x 20.3 cm

Weight: 500 g

Display type: Digital

Insulation resistance (max.): 10 GΩ

Voltage reading range (max.): 600 V

Voltage reading range (min.): 0 V

Reading category: CAT IV 600 V

Width: 10 cm

Height: 20.3 cm

Display (details): LCD

Test voltage: 50 V, 100 V, 250 V, 500 V, 1000 V (+20 %, -0 %)

Reading range - voltage: 0 - 600 V AC/DC

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 122160 Fluke 1507 Insulation tester 50 V, 100 V, 250 V, 500 V, 1000 V 10 GΩ

Conformity certificate

English

Conformity certificate 122160 Fluke 1507 Insulation tester 50 V, 100 V, 250 V, 500 V, 1000 V 10 GΩ

Description

The insulation multimeters from Fluke combine the functions of a digital insulation tester and a fully equipped digital real effective multimeter in one compact and portable device, offering optimal versatility when troubleshooting and during preventive maintenance.

Features

Selectable test voltages for different uses
Slender button head with release key for simple and reliable measurements
Automatic discharge of capacitive voltages for extra protection of the user
Recognition of current carrying circuits avoids insulation tests with voltages over 30 V and increases the protection for the user
Automatic calculation of the polarity index and the dielectric absorption ratio
Automatic power-off for longer battery life
Large display with backlighting
Continuity test (200 mA).

Scope of delivery

TP165x slender probe with trigger key
TL224 SureGrip silicone test lead set
TP74 probe tips with 4 mm banana plugs
Alligator clips
Instructions for use
4 batteries (type AA).

Hints

Comparison function (good/bad) for quick execution of repetitive testing
