Name: FMS55ESB Eltako EnOcean Pushbutton Surface-mount Max. range (open field) 30 m
Brand: Eltako
SKU: 2256223
Availability: SoldOut

A blank, square light switch surround in white plastic, mounted on a wall.

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 114.99 / piece)

€ 114.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Wireless multi-sensor T+ H + E + M, solar cell, pure white glossy E-Design55

With integrated solar cell
For single mounting or mounting in E Design 55 switch system
Temperature, humidity, illumination, acceleration and magnetic contact sensor

Technical specifications

Color: Pure white glossy

Product type: Pushbutton

Series: Eltako

Dim: (W x H x D) 80 x 80 x 14 mm

Transfer Standard (Smart Home): EnOcean

: IP20

Power supply (LOV): solar-powered
battery-powered

Mounting type: Surface-mount

Data transfer (Smart Home): Wireless

Frequency: 868 MHz

: 30 m

Width: 80 mm

Height: 80 mm

Depth: 14 mm

Hub: Not required, optional for remote access

Data exchange: Bidirectional (bi)

: n.rel.

Features: Test function

: Other

: 30 m

: FALSE

: FALSE

: FALSE

: FALSE

: 868 MHz

: FALSE

: FALSE

: IP20

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 2256223 FMS55ESB Eltako EnOcean Pushbutton Surface-mount Max. range (open field) 30 m

User & Safety Instructions

User & Safety Instructions 2256223 FMS55ESB Eltako EnOcean Pushbutton Surface-mount Max. range (open field) 30 m

Description

Wireless multi-sensor pure white glossy for single mounting 80 x 80 x 14 mm or mounting in the E Design55 switch system. With integrated solar cell and CR1632 battery (not included in delivery). Smart home sensor. This multi-sensor has integrated temperature, humidity, illumination, acceleration and magnetic contact sensors in one housing. It transmits all data via EnOcean radio in the Eltako building radio. The integrated solar cell generates the required energy from the ambient light indoors. This energy is stored internally, so that the multi-sensor also works for several days without light. The multi-sensor has an NFC interface, which allows you to configure it via an NFC reader, smartphone or tablet. On delivery, the EEP: D2-14-41 is active, which contains the data of all sensors. Via the NFC interface, the parameters of the sensors can be changed and individual EEPs can be selected: A5-04-03, A5-02-05, A5-06-02, A5-06-03, A5-14-05 or D2-00-01.
