Frei RNLB08G0102B0E Resistor ladder 1 kΩ THT SIP 8 0.2 W 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 0.30151
50
9% = € 0.03
€ 0.27404
100
13% = € 0.04
€ 0.26307
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 0.30151 / piece)
€ 0.30
plus VAT.
Technical specifications
- ESD Packaging: No ESD
- Series RNY
- Delivery form: Loose
- Resistance value 1 kOhm
- Resistance unit: KOhm
- Resistance value_1: 1
- Resistance tolerance: ±5 %
- Rated output: 0.2 W
- Max. OPERATING VOLTAGE (DC) 100 V DC
- Max. OPERATING VOLTAGE (AC) 100 V AC
- Temperature coefficient, typ.: 100 ppm/°
- Number of resistors: 4
- Number of pins: 8
- Type
THT
- Type
SIP 8
- Resistance
1 kΩ
- Power rating
0.2 W
- Tolerance ±
5 %
- Temperature coefficient
100 ppm/°C
- CS
2.54 mm
- Length
20.4 mm
- Width
2.5 mm
- Height
5.1 mm
- Content
1 pc(s)
- Dim
(L x W x H) 20.4 x 2.5 x 5.1 mm
- Type
RNLB08G0102B0E
- Product type
Resistor ladder
Documents & Downloads
Datasheet
Datasheet 3523326 Frei RNLB08G0102B0E Resistor ladder 1 kΩ THT SIP 8 0.2 W 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3523326 Frei RNLB08G0102B0E Resistor ladder 1 kΩ THT SIP 8 0.2 W 1 pc(s)
Description
Thick film resistor networks Y series 1/
This text is machine translated.
This text is machine translated.
Features
- • Series connection
- • High stability
- • Single inLine
