Name: Fusion splicer NP-CFS100 NetPeppers CFS100
Brand: NetPeppers
SKU: 2533329
Availability: BackOrder

A splice machine with a digital display shows operating modes and settings. The device has a robust construction and functions for optical fibre connection.

A portable, rugged electronic device with a display and controls, suitable for technical or industrial applications.

An orange fusion splicing machine with a fold-out screen, used for connecting optical fibre cables.

$'A portable refractometer with a black storage case, connected by a cable, standing on a white surface.'$

Portable fibre optic fusion splicer with accessories: protective case, cables, adapters and manual laid out on a table. Ideal for fibre optic installation.

Fibre optic splicing machine in action, showing the process of fusion-joining optical fibre cables with an electric arc between the fibres.

1/6

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 5 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 4,405.00 / piece)

€ 4,405.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

NetPeppers core-centered splicing device for professional splicing of all common fiber types

Splices all conventional fiber types such as multimode, singlemode fibers, pigtails, patch cables or SOCsAutomatic 3-axis alignment system with core centeringAutomatic detection of the inserted fiber type and independant configuration of all important parametersFiber load detection before the splicing process with recognition of the axial offset, fiber break angle and mold testFast splice time of average less than 9 and heat time of heat shrink furnace less than 25 secondsOptical evaluation of the finished splice based on form and attenuation assessmentFoldable display for comfortable use of the device from two working positionsHeat-shrink furnace for splice protectors up to 60 mmAutomatic arc adjustment, temperature and air pressure compensationLED lighting of the splice location, connection of an external work light possible

Technical specifications

Product type: Fusion splicer

Display: LCD

Splicing mode: Automatic
Manual

Optical display: Yes

Burns per electrode: 5000

Dim: (L x W x H) 147 x 138 x 135 mm

Weight: 1.850 g

: 25 s

Features: Touchscreen

Width: 138 mm

Height: 135 mm

Length: 147 mm

Splicing time: 9 s

Type: CFS100

Documents & Downloads

Datasheet

Datasheet 2533329 Fusion splicer NP-CFS100 NetPeppers CFS100

User & Safety Instructions

User & Safety Instructions 2533329 Fusion splicer NP-CFS100 NetPeppers CFS100

Description

The CFS-100 is a core-centered, 3-axis controlled fusion splicing device that is the perfect companion for splicing small and large projects. The lightweight and flexible precision splicing device allows G.651 fibers to be spliced with attenuation below 0.01 dB and G.652 fibers below 0.02 dB attenuation (typical). Equipped with removable universal fiber holders, SOC holder and internal thermometer as well as barometer, the CFS-100 can be used everywhere. Fast five second start time and an average of nine seconds splicing time as well as the automatic heating oven for heat-shrink protective sleeves accelerate the workflow and lead to more splicing per time.

This text is machine translated.

Features

State-of-the-art splice technology at workThanks to the core centering and its extensive automatic functions, the CFS-100 is not only highly precise, but also very easy to use.Compatibility that is second to noneWhether multimode, singlemode fibers, pigtails, patch cables or SOCs: The CFS-100 splices all common fiber types.Workflow at splice locationSplicing doesn't have to be uncomfortable. Set up your splicing area according to your requirements. Thanks to the folding display, you can operate the device from the front and back.

Scope of delivery

CFS-100 Splice machinePair of electrodes (pre-installed)Pair of universal fiber holders (4 in 1)SOC-fiber holder1 SOC Shrink furnace adapterLi-ion batteryFiber Cleaver OFC-30Heat-sink for heat-shrink furnace Power adapter including cold device cable1 Micro-USB cable (for data transfer)Hard caseCarrying strap Hard shell caseQuick guideManualCalibration certificateAssembly tool

Hints

IMPORTANT! Please observe the general safety regulations when working with glass fibers
