Name: Gedore 2927268 Puller set Clamping range (details) 70 - 260 mm No. of hooks 3
Brand: Gedore
SKU: 1906491
Availability: BackOrder

A set of pullers in a foam insert with various tool sizes and components, suitable for mechanical work.

EAN:

Part number:

Item no:

Dispatches on Thu 5 Nov

3 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 715.00 / piece)

€ 715.00

incl. VAT

Only 3 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

1100 CT 2-1. 04/12 A-GEDORE-Abzieher-Srt. Indoor/Outdoor, in 2/2 L-Boxx 136 module
Universal Indoor/Outdoor Puller Set
Max. Load 3 and 5 t
For spans (SW) up to Ø 200 mm Ø 70-260 mm inside, outside, and planing depth (ST) up to 300 mm
2 additional spindles for max. clamping depth
Die-forged cross beams for more safety
Spindles with special coating, in which the grease is not necessary
At 3 of 4 spindles can be rotated the spindle tip (ball/tip)
Bending moment reinforced traverse no. 1.04 for higher stress
Quick release hook with self-supporting T-profile for better power transfer
Reinforced hook-shaped
Quick release for comfortable and fast loosen and tighten the hook
Each 2 all-steel extensions 100 and 150 mm with Hook brake for quick setting the hook
Check tool insert for clean storage of tools
The tools are completely in the foam countersunk, thus, several deposits stacked
The insert can be used both for L-Boxx 136 as well as in all drawers can be used that a height of min. 90 mm

Clamping range: 70 - 260 mm

Dim: (L x W x H) 357 x 310 x 90 mm

Weight: 7.4 kg

Content: 1 pc(s)

Hooks: 3

Max. length: 357 mm

Product type: Puller set

Width: 310 mm

Height: 90 mm

Length: 357 mm

Span width (max.): 260 mm

Span depth (max.): 300 mm

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1906491 Gedore 2927268 Puller set Clamping range (details) 70 - 260 mm No. of hooks 3

Information

Information 1906491 Gedore 2927268 Puller set Clamping range (details) 70 - 260 mm No. of hooks 3

Features

Max. capacity 3 and 5 t
For clamping depths up to Ø 200 mm external, Ø 70-260 mm internal, and clamping reach up to 300 mm
In 3 of 4 spindles the spindle tip (ball/tip) can be rotated
Quick-release pulling legs with intregral T-profile for a better transmission of force
The forged leg feet are very slim particularly suitable for barely accessible places
2 rigid extensions each 100 and 150 mm with leg brake for quick adjustment of the legs
1100 CT2-1.04/12A to retrofit existing L-BOXX®es 136
With Check-Tool insert for quick check of completeness
As tools are fully sunk in the foam, the equipped insert can be stacked
Insert for use in drawers with min. dimensions 400 x 310 x 90 mm

Description

Features

Max. capacity 3 and 5 t
For clamping depths up to Ø 200 mm external, Ø 70-260 mm internal, and clamping reach up to 300 mm
In 3 of 4 spindles the spindle tip (ball/tip) can be rotated
Quick-release pulling legs with intregral T-profile for a better transmission of force
The forged leg feet are very slim particularly suitable for barely accessible places
2 rigid extensions each 100 and 150 mm with leg brake for quick adjustment of the legs
1100 CT2-1.04/12A to retrofit existing L-BOXX®es 136
With Check-Tool insert for quick check of completeness
As tools are fully sunk in the foam, the equipped insert can be stacked
Insert for use in drawers with min. dimensions 400 x 310 x 90 mm
