Hahn BV EI 304 8014 PCB mount transformer 1 x 230 V 1 x 9 V AC 2.1 VA 233 mA
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.92
3
6% = € 0.61
€ 10.31
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.92 / piece)
€ 10.92
plus VAT.
Highlights & Details
Transformer/ Transformer P: 230V S:9V/2.1VA
- 1 x 230 V
- 1 x 9 V AC
- 233 mA
- 2.1 VA
Technical specifications
- Output voltage
9 V AC
- Output voltage (number x voltage)
1 x 9 V AC
- Output current
233 mA
- No. of inputs
1 x
- No. of outputs
1 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
2.1 VA
- Width
27.50 mm
- Height
27.40 mm
- Length
32.50 mm
- Type
BV EI 304 8014
- Content
1 pc(s)
- Dim
(L x W x H) 32.50 x 27.50 x 27.40 mm
- Frequency
50 - 60 Hz
- RoHS-compliant
Yes
- Max. ambient temperature
70 °C
- Product type
PCB mount transformer
Documents & Downloads
Datasheet
Datasheet 3135731 Hahn BV EI 304 8014 PCB mount transformer 1 x 230 V 1 x 9 V AC 2.1 VA 233 mA
User & Safety Instructions
User & Safety Instructions 3135731 Hahn BV EI 304 8014 PCB mount transformer 1 x 230 V 1 x 9 V AC 2.1 VA 233 mA
Description
Several 100 types are synonymous with high safety and durability when used on printed circuit boards, in household appliances, in entertainment electronics, heating and regulation technology as well as in the assembly industry. Transformers for special requirements with low no-load capacity are also included in the delivery program.
This text is machine translated.
This text is machine translated.
Features
- Circuit breaker
- Vacuum cast, two-chamber winding
- 100% routine testing
- Excellent temperature change characteristics
- Self-extinguishing sealing and hood material
- Minimum size
