Image similar
Image similar
Hahn BV EI 306 8007 PCB mount transformer 1 x 230 V 2 x 12 V AC 2.8 VA 117 mA
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 12.60
3
6% = € 0.70
€ 11.90
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 12.60 / piece)
€ 12.60
plus VAT.
Highlights & Details
Transformer/ Transformer P: 230V S:2x12V/2.8VA
- 1 x 230 V
- 2 x 12 V AC
- 117 mA
- 2.8 VA
Technical specifications
- Output voltage
12 V AC
- Output voltage (number x voltage)
2 x 12 V AC
- Output current
117 mA
- No. of inputs
1 x
- No. of outputs
2 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
2.8 VA
- Width
27.50 mm
- Height
34 mm
- Length
32.50 mm
- Type
BV EI 306 8007
- Content
1 pc(s)
- Dim
(L x W x H) 32.50 x 27.50 x 34 mm
- Frequency
50 - 60 Hz
- RoHS-compliant
Yes
- Max. ambient temperature
70 °C
- Product type
PCB mount transformer
Documents & Downloads
Datasheet
Datasheet 3135741 Hahn BV EI 306 8007 PCB mount transformer 1 x 230 V 2 x 12 V AC 2.8 VA 117 mA
User & Safety Instructions
User & Safety Instructions 3135741 Hahn BV EI 306 8007 PCB mount transformer 1 x 230 V 2 x 12 V AC 2.8 VA 117 mA
Description
Several 100 types are synonymous with high safety and durability when used on printed circuit boards, in household appliances, in entertainment electronics, heating and regulation technology as well as in the assembly industry. Transformers for special requirements with low no-load capacity are also included in the delivery program.
This text is machine translated.
This text is machine translated.
Features
- Circuit breaker
- Vacuum cast, two-chamber winding
- 100% routine testing
- Excellent temperature change characteristics
- Self-extinguishing sealing and hood material
- Minimum size
