Name: HELU 34350-100 Data transfer cable 4 x 0.5 mm² Grey 100 m
Brand: HELU
SKU: 2826338

A grey cable with the inscription 'HELUAKBEL® JZ-500 HCH CE'. Colourful cores are visible at the left end.

Product type

Data transfer cable

No. of leads

4 x

Cross section (each core)

0.5 mm²

Cable features

Shielded

Cross section

4 x 0.5 mm²

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Weight 102 kg/km

Product type: Data transfer cable

No. of leads: 4 x

Cross section (each core): 0.5 mm²

Cross section: 4 x 0.5 mm²

Cable features: Shielded

Outside Ø: 6.8 mm

Factory colour: Grey

Content: 100 m

Bend radius (no. of ODs for fixed installation): 7.5

Shielded: Yes

Manufacturer part #: 34350-100

Wire ID code: Core identification according to DIN VDE 0815, colored ring marking of the bundles

Insulation: Polymer

Core layout: Plain copper wire, multi-strand

RoHS-compliant: Yes

Min. temperature range (flexible installation): -5 °C

Max. temperature range (flexible installation): 50 °C

Min. temperature range (fixed installation): -30 °C

Max. temperature range (fixed installation): 70 °C

Certification marks: EAC

Max. length sold by the metre: 100 m

Type: JE-LIHCH 2x2x0,5 GR

Documents & Downloads

Datasheet

Datasheet 2826338 HELU 34350-100 Data transfer cable 4 x 0.5 mm² Grey 100 m

User & Safety Instructions

User & Safety Instructions 2826338 HELU 34350-100 Data transfer cable 4 x 0.5 mm² Grey 100 m

Description

Halogen-free installation cables with improved fire performance in the event of fire are used for telephone transmission, measurement and signal purposes. The copper braid (C) protects the transmission circuits against electrical interference fields. A fire transmission is prevented by the high oxygen index of the insulation and the sheath. They do not release corrosive gases in case of fire. They are preferably used for remote installation within buildings. The cables are suitable for fixed laying in fire and fire-endangered areas, dry and damp rooms as well as in, on and under plaster. Not approved for heavy current installation or for underground installation. EMC = electromagnetic compatibility; to optimize the EMC properties, we recommend that copper braid contacts are made on both sides and over a wide area.
