Image similar
HELU F-C-PURö-OZ Control lead 2 x 0.50 mm² Grey 21200-500 500 m
Product type
Control lead
No. of leads
2 x
Cross section (each core)
0.50 mm²
Cable type
F-C-PURö-OZ
Outside Ø
5.60 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Control lead
- No. of leads
2 x
- Content
500 m
- Cross section (each core)
0.50 mm²
- Cable features
Shielded
Ozone-resistant
UV-resistant
Charpy impact tested
incl. graduation (metres)
Oil-resistant
Oil- and abrasion-resistant
- Cable type
F-C-PURö-OZ
- Outside Ø
5.60 mm
- Packaged
Yes
- Wire ID code
DIN VDE 0293
- Bend radius (no. of ODs for fixed installation)
5
- Bend radius (no. of ODs for flexible installation)
10
- Halogen-free
No
- Manufacturer part #
21200-500
- Factory colour
Grey
- Insulation material
PUR
- Insulation
PVC
- Core layout
Plain Cu braid, according to DIN VDE 0295 class 5, fine strand
- Material (details)
PVC
- Sold per metre
No
- Nominal voltage
500 V
- Nominal voltage U0
300 V
- Number-coded
Yes
- Cross section
2 x 0.50 mm²
- RoHS-compliant
Yes
- Suited for cable carriers
No
- Max. temperature range (flexible installation)
+80 °C
- Min. temperature range (flexible installation)
-20 °C
- Max. temperature range (fixed installation)
+80 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
21200-500
Documents & Downloads
Datasheet
Datasheet 3040791 HELU F-C-PURö-OZ Control lead 2 x 0.50 mm² Grey 21200-500 500 m
User & Safety Instructions
User & Safety Instructions 3040791 HELU F-C-PURö-OZ Control lead 2 x 0.50 mm² Grey 21200-500 500 m
