HELU JB-750 HMH Control lead 3 G 1.5 mm² Grey 11965-1000 1000 m
Product type
Control lead
No. of leads
3 G
Cross section (each core)
1.5 mm²
Cable type
JB-750 HMH
Outside Ø
7.80 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Control lead
- No. of leads
3 G
- Content
1000 m
- Cross section (each core)
1.5 mm²
- Cable features
Flame-retardant
Flexible
Halogen-free
incl. graduation (metres)
Oil-resistant
- Cable type
JB-750 HMH
- Outside Ø
7.80 mm
- Packaged
Yes
- Wire ID code
DIN VDE 0293
- Bend radius (no. of ODs for fixed installation)
5
- Bend radius (no. of ODs for flexible installation)
10
- Halogen-free
Yes
- Manufacturer part #
11965-1000
- Factory colour
Grey
- Insulation material
Polymer
- Insulation
PVC
- Core layout
Plain Cu braid, according to DIN VDE 0295 class 5, fine strand
- Material (details)
PVC
- Sold per metre
No
- Nominal voltage
750 V
- Nominal voltage U0
450 V
- Number-coded
Yes
- Cross section
3 G 1.5 mm²
- RoHS-compliant
Yes
- Suited for cable carriers
No
- Max. temperature range (flexible installation)
+70 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
+70 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
11965-1000
