Name: HELU JZ-500-C Black Control lead 5 G 0.75 mm² Black 10945-500 500 m
Brand: HELU
SKU: 3042077

Black cable labelled 'HELUKABEL JZ-500 0-black 12G 1.5 0.6/1kV' with CE marking.

Image similar

Product type

Control lead

No. of leads

5 G

Cross section (each core)

0.75 mm²

Cable type

JZ-500-C Black

Outside Ø

8.20 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 5 G

Content: 500 m

Cross section (each core): 0.75 mm²

Cable features: Oil-resistant
chemical-resistant
incl. graduation (metres)
Shielded
UV-resistant
Flame-retardant

Cable type: JZ-500-C Black

Outside Ø: 8.20 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 5

Bend radius (no. of ODs for flexible installation): 10

Halogen-free: No

Manufacturer part #: 10945-500

Factory colour: Black

Insulation material: PVC

Insulation: PVC

Core layout: Plain Cu braid, according to DIN VDE 0295 class 5, fine strand

Material (details): PVC

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Test voltage: 4000 V
2000 V

Cross section: 5 G 0.75 mm²

RoHS-compliant: Yes

Suited for cable carriers: No

Max. temperature range (flexible installation): +80 °C

Min. temperature range (flexible installation): -15 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: 10945-500
