HELU JZ-500 Control lead 7 G 0.50 mm² Grey 11205-100 100 m
Product type
Control lead
No. of leads
7 G
Cross section (each core)
0.50 mm²
Cable type
JZ-500
Outside Ø
6.70 mm
EAN:
Part number:
Item no:
Technical specifications
- Feature: Hard to burn
- Product type
Control lead
- No. of leads
7 G
- Content
100 m
- Cross section (each core)
0.50 mm²
- Cable features
Halogen-free
Flame-retardant
incl. graduation (metres)
Oil-resistant
Flexible
- Cable type
JZ-500
- Outside Ø
6.70 mm
- Packaged
Yes
- Wire ID code
DIN VDE 0293
- Bend radius (no. of ODs for fixed installation)
4
- Bend radius (no. of ODs for flexible installation)
12.5
- Halogen-free
Yes
- Manufacturer part #
11205-100
- Factory colour
Grey
- Insulation material
Polymer
- Core layout
Cu-strand blank, according to DIN VDE 0295 Class 5, fine-strand, BS 6360 cl.5, IEC 60228 cl.5
- Sold per metre
No
- Nominal voltage
500 V
- Nominal voltage U0
300 V
- Test voltage
2000 V
- Cross section
7 G 0.50 mm²
- RoHS-compliant
Yes
- Max. temperature range (flexible installation)
70 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
70 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
11205-100
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3045796 HELU JZ-500 Control lead 7 G 0.50 mm² Grey 11205-100 100 m
