Name: HELU JZ-500 HMH Control lead 4 x 1.5 mm² Black 12763-500 500 m
Brand: HELU
SKU: 3041551

Black electrical cable with inscription 'HELUKABEL JZ-600 HMH 250 1.0 6MM² 4X70 0.6/1 KV halogen-free'.

Image similar

Product type

Control lead

No. of leads

4 x

Cross section (each core)

1.5 mm²

Cable type

JZ-500 HMH

Outside Ø

9.60 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 4 x

Content: 500 m

Cross section (each core): 1.5 mm²

Cable features: Oil-resistant
incl. graduation (metres)
Flame-retardant
Flexible
Halogen-free

Cable type: JZ-500 HMH

Outside Ø: 9.60 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 7.5

Halogen-free: Yes

Manufacturer part #: 12763-500

Factory colour: Black

Insulation material: Polymer

Insulation: others

Core layout: Plain Cu braid, according to DIN VDE 0295 class 5, fine strand

Material (details): Halogen-free TM7 polymer

Sold per metre: No

Nominal voltage: 1000 V

Nominal voltage U0: 600 V

Number-coded: Yes

Cross section: 4 x 1.5 mm²

RoHS-compliant: Yes

Suited for cable carriers: No

Max. temperature range (flexible installation): +80 °C

Min. temperature range (flexible installation): -15 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: 12763-500
