Name: HELU JZ-500 PUR Control lead 3 G 1.5 mm² Grey 23361-500 500 m
Brand: HELU
SKU: 3042218

In the image, there is a grey cable labelled 'HELUKABEL 25800 PUR 4G1.0MM² 23979 300/500 V'.

Image similar

Product type

Control lead

No. of leads

3 G

Cross section (each core)

1.5 mm²

Cable type

JZ-500 PUR

Outside Ø

6.80 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 3 G

Content: 500 m

Cross section (each core): 1.5 mm²

Cable features: incl. graduation (metres)
Flame-retardant
Charpy impact tested
UV-resistant
Ozone-resistant

Cable type: JZ-500 PUR

Outside Ø: 6.80 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 5

Bend radius (no. of ODs for flexible installation): 10

Halogen-free: No

Manufacturer part #: 23361-500

Factory colour: Grey

Insulation material: PUR

Insulation: PVC

Core layout: Plain Cu braid, according to DIN VDE 0295 class 5, fine strand

Material (details): PVC

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Cross section: 3 G 1.5 mm²

RoHS-compliant: Yes

Suited for cable carriers: No

Max. temperature range (flexible installation): +80 °C

Min. temperature range (flexible installation): -15 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: 23361-500
