Name: HELU JZ-500 PUR Control lead 3 G 2.5 mm² Grey 23374-500 500 m
Brand: HELU
SKU: 3041731

Cable marked 'HELUKABEL JZ-500 PUR 4G1.0MM² 23079 300/500 V 00100025 CE', showing technical specifications.

Image similar

Product type

Control lead

No. of leads

3 G

Cross section (each core)

2.5 mm²

Cable type

JZ-500 PUR

Outside Ø

8.30 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 3 G

Content: 500 m

Cross section (each core): 2.5 mm²

Cable features: incl. graduation (metres)
UV-resistant
Ozone-resistant
Charpy impact tested

Cable type: JZ-500 PUR

Outside Ø: 8.30 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 7.5

Halogen-free: No

Manufacturer part #: 23374-500

Factory colour: Grey

Insulation material: PUR

Insulation: PVC

Core layout: Plain Cu braid, according to DIN VDE 0295 class 5, fine strand

Material (details): PVC

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Cross section: 3 G 2.5 mm²

RoHS-compliant: Yes

Suited for cable carriers: No

Max. temperature range (flexible installation): +80 °C

Min. temperature range (flexible installation): -15 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: 23374-500
