Image similar
HELU JZ-602-CY Control lead 3 G 1 mm² Grey 82980-1000 1000 m
Product type
Control lead
No. of leads
3 G
Cross section (each core)
1 mm²
Cable type
JZ-602-CY
Outside Ø
8.50 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Control lead
- No. of leads
3 G
- Content
1000 m
- Cross section (each core)
1 mm²
- Cable features
Oil-resistant
incl. graduation (metres)
Shielded
Flame-retardant
- Cable type
JZ-602-CY
- Outside Ø
8.50 mm
- Packaged
Yes
- Wire ID code
DIN VDE 0293
- Bend radius (no. of ODs for fixed installation)
4
- Bend radius (no. of ODs for flexible installation)
10
- Halogen-free
No
- Manufacturer part #
82980-1000
- Factory colour
Grey
- Insulation material
PVC
- Insulation
PVC
- Core layout
Cu-strand blank, according to DIN VDE 0295 class 5, fine-strand
- Material (details)
PVC
- Sold per metre
No
- Nominal voltage
600 V
- Number-coded
Yes
- Cross section
3 G 1 mm²
- RoHS-compliant
Yes
- Suited for cable carriers
No
- Max. temperature range (flexible installation)
+90 °C
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (fixed installation)
+90 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
82980-1000
Documents & Downloads
Datasheet
Datasheet 3039269 HELU JZ-602-CY Control lead 3 G 1 mm² Grey 82980-1000 1000 m
User & Safety Instructions
User & Safety Instructions 3039269 HELU JZ-602-CY Control lead 3 G 1 mm² Grey 82980-1000 1000 m
