Name: HELU JZ-603 Control lead 3 G 1.5 mm² Grey 83683-1000 1000 m
Brand: HELU
SKU: 3039358

Close-up of a cable with labelling: 'H05VV-F 3G1.0mm²', a flexible electrical cable with CE marking.

Image similar

Product type

Control lead

No. of leads

3 G

Cross section (each core)

1.5 mm²

Cable type

JZ-603

Outside Ø

8 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 3 G

Content: 1000 m

Cross section (each core): 1.5 mm²

Cable features: Flame-retardant
incl. graduation (metres)
Oil-resistant

Cable type: JZ-603

Outside Ø: 8 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 5

Bend radius (no. of ODs for flexible installation): 10

Halogen-free: No

Manufacturer part #: 83683-1000

Factory colour: Grey

Insulation material: PVC

Insulation: PVC

Core layout: Plain Cu braid, according to DIN VDE 0295 class 5, fine strand

Material (details): PVC

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Test voltage: 3000 V

Cross section: 3 G 1.5 mm²

RoHS-compliant: Yes

Suited for cable carriers: No

Max. temperature range (flexible installation): +70 °C

Min. temperature range (flexible installation): -5 °C

Max. temperature range (fixed installation): +70 °C

Min. temperature range (fixed installation): -40 °C

Type: 83683-1000
