Name: HELU MEGAFLEX® 500 Control lead 4 x 1 mm² Grey 13536-500 500 m
Brand: HELU
SKU: 3041940

Cross-section of a multi-core cable with metal sheathing, labelled 'Multipair, 18 AWG, 600V, FT1'.

Image similar

Product type

Control lead

No. of leads

4 x

Cross section (each core)

1 mm²

Cable type

MEGAFLEX® 500

Outside Ø

7.30 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 4 x

Content: 500 m

Cross section (each core): 1 mm²

Cable features: Flame-retardant
Flexible
Halogen-free
Ozone-resistant
UV-resistant
incl. graduation (metres)
Oil-resistant
Shielded

Cable type: MEGAFLEX® 500

Outside Ø: 7.30 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 10

Halogen-free: Yes

Manufacturer part #: 13536-500

Factory colour: Grey

Insulation material: Polymer

Insulation: others

Core layout: Plain Cu braid, according to DIN VDE 0295 class 5, fine strand

Material (details): Special halogen-free polymer

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Test voltage: 3000 V

Cross section: 4 x 1 mm²

RoHS-compliant: Yes

Suited for cable carriers: No

Max. temperature range (flexible installation): +80 °C

Min. temperature range (flexible installation): -30 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: 13536-500
