HELU OB-750 Control lead 2 x 4 mm² Grey 11121-500 500 m
Product type
Control lead
No. of leads
2 x
Cross section (each core)
4 mm²
Cable type
OB-750
Outside Ø
10.60 mm
EAN:
Part number:
Item no:
Technical specifications
- Product type
Control lead
- No. of leads
2 x
- Content
500 m
- Cross section (each core)
4 mm²
- Cable features
Flexible
Colour-coded
Oil-resistant
chemical-resistant
- Cable type
OB-750
- Outside Ø
10.60 mm
- Packaged
Yes
- Wire ID code
Colour, wire identification according to JB/OB color code
- Bend radius (no. of ODs for fixed installation)
4
- Bend radius (no. of ODs for flexible installation)
7.5
- Halogen-free
No
- Manufacturer part #
11121-500
- Factory colour
Grey
- Insulation material
PVC
- Insulation
Special PVC
- Core layout
Cu-strand blank, according to DIN VDE 0295 Class 5, fine-strand
- Material (details)
PVC
- Sold per metre
No
- Nominal voltage
750 V
- Nominal voltage U0
450 V
- Number-coded
No
- Test voltage
4000 V
- Cross section
2 x 4 mm²
- RoHS-compliant
Yes
- Suited for cable carriers
No
- Max. temperature range (flexible installation)
+80 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
+80 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
11121-500
