HELU OZ-600 Control lead 4 x 2.5 mm² Black 10693-1000 1000 m
Product type
Control lead
No. of leads
4 x
Cross section (each core)
2.5 mm²
Cable type
OZ-600
Outside Ø
11.30 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Control lead
- No. of leads
4 x
- Content
1000 m
- Cross section (each core)
2.5 mm²
- Cable features
Oil-resistant
incl. graduation (metres)
Flame-retardant
Flexible
UV-resistant
chemical-resistant
- Cable type
OZ-600
- Outside Ø
11.30 mm
- Packaged
Yes
- Wire ID code
DIN VDE 0293
- Bend radius (no. of ODs for fixed installation)
4
- Bend radius (no. of ODs for flexible installation)
7.5
- Halogen-free
No
- Manufacturer part #
10693-1000
- Factory colour
Black
- Insulation material
PVC
- Insulation
PVC
- Core layout
Plain Cu braid, according to DIN VDE 0295 class 5, fine strand
- Material (details)
PVC
- Sold per metre
No
- Nominal voltage
1000 V
- Nominal voltage U0
600 V
- Number-coded
Yes
- Test voltage
8000 V
- Cross section
4 x 2.5 mm²
- RoHS-compliant
Yes
- Suited for cable carriers
No
- Max. temperature range (flexible installation)
+80 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
+80 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
10693-1000
Documents & Downloads
Datasheet
Datasheet 3039083 HELU OZ-600 Control lead 4 x 2.5 mm² Black 10693-1000 1000 m
User & Safety Instructions
User & Safety Instructions 3039083 HELU OZ-600 Control lead 4 x 2.5 mm² Black 10693-1000 1000 m
