Image similar
HELU OZ-600-Y-CY Control lead 2 x 1 mm² Black 11516-500 500 m
Product type
Control lead
No. of leads
2 x
Cross section (each core)
1 mm²
Cable type
OZ-600-Y-CY
Outside Ø
9.20 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Control lead
- No. of leads
2 x
- Content
500 m
- Cross section (each core)
1 mm²
- Cable features
Oil-resistant
incl. graduation (metres)
Flame-retardant
Flexible
UV-resistant
chemical-resistant
Shielded
- Cable type
OZ-600-Y-CY
- Outside Ø
9.20 mm
- Packaged
Yes
- Wire ID code
DIN VDE 0293
- Bend radius (no. of ODs for fixed installation)
5
- Bend radius (no. of ODs for flexible installation)
10
- Halogen-free
No
- Manufacturer part #
11516-500
- Factory colour
Black
- Insulation material
PVC
- Insulation
PVC
- Core layout
Plain Cu braid, according to DIN VDE 0295 class 5, fine strand
- Material (details)
PVC
- Sold per metre
No
- Nominal voltage
1000 V
- Nominal voltage U0
600 V
- Number-coded
Yes
- Test voltage
4000 V
- Cross section
2 x 1 mm²
- RoHS-compliant
Yes
- Suited for cable carriers
No
- Max. temperature range (flexible installation)
+80 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
+80 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
11516-500
Documents & Downloads
Datasheet
Datasheet 3041607 HELU OZ-600-Y-CY Control lead 2 x 1 mm² Black 11516-500 500 m
User & Safety Instructions
User & Safety Instructions 3041607 HELU OZ-600-Y-CY Control lead 2 x 1 mm² Black 11516-500 500 m
