Name: HELU Y-CY-JZ Control lead 4 G 0.50 mm² Grey 16322-500 500 m
Brand: HELU
SKU: 3042292

Grey cable with metal braiding and coloured wires in cross-section, printed with: 'HELUKABEL 1000V 3G2.5'.

Image similar

Product type

Control lead

No. of leads

4 G

Cross section (each core)

0.50 mm²

Cable type

Y-CY-JZ

Outside Ø

6.50 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 4 G

Content: 500 m

Cross section (each core): 0.50 mm²

Cable features: Oil-resistant
chemical-resistant
incl. graduation (metres)
Flexible
Shielded

Cable type: Y-CY-JZ

Outside Ø: 6.50 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 7.5

Halogen-free: No

Manufacturer part #: 16322-500

Factory colour: Grey

Insulation material: PVC

Insulation: PVC

Core layout: Plain Cu braid, according to DIN VDE 0295 class 5, fine strand

Material (details): PVC

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Test voltage: 4000 V

Cross section: 4 G 0.50 mm²

RoHS-compliant: Yes

Suited for cable carriers: No

Max. temperature range (flexible installation): +80 °C

Min. temperature range (flexible installation): -10 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: 16322-500
