HELU Y-CY-JZ Control lead 6 G 0.75 mm² Transparent 16227-1000 1000 m
Product type
Control lead
No. of leads
6 G
Cross section (each core)
0.75 mm²
Cable type
Y-CY-JZ
Outside Ø
9.90 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Control lead
- No. of leads
6 G
- Content
1000 m
- Cross section (each core)
0.75 mm²
- Cable features
Flexible
Shielded
incl. graduation (metres)
Flame-retardant
chemical-resistant
Oil-resistant
- Cable type
Y-CY-JZ
- Outside Ø
9.90 mm
- Packaged
Yes
- Wire ID code
DIN VDE 0293
- Bend radius (no. of ODs for fixed installation)
4
- Bend radius (no. of ODs for flexible installation)
12.5
- Halogen-free
No
- Manufacturer part #
16227-1000
- Factory colour
Transparent
- Insulation material
PVC
- Insulation
PVC
- Core layout
Plain Cu braid, according to DIN VDE 0295 class 5, fine strand
- Material (details)
PVC
- Sold per metre
No
- Nominal voltage
500 V
- Nominal voltage U0
300 V
- Number-coded
Yes
- Test voltage
4000 V
- Cross section
6 G 0.75 mm²
- RoHS-compliant
Yes
- Suited for cable carriers
No
- Max. temperature range (flexible installation)
+80 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
+80 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
16227-1000
Documents & Downloads
Datasheet
Datasheet 3039187 HELU Y-CY-JZ Control lead 6 G 0.75 mm² Transparent 16227-1000 1000 m
User & Safety Instructions
User & Safety Instructions 3039187 HELU Y-CY-JZ Control lead 6 G 0.75 mm² Transparent 16227-1000 1000 m
