Name: Hirschmann 932 186-100-1 G 30 W 3 F Mains Voltage Connector Black Pins:3 + PE
Brand: Hirschmann
SKU: 735151
Availability: InStock

A hydraulic pressure switch with a hexagonal connection and black plastic housing, commonly used for monitoring pressure systems.

'Technical drawing of a square connector with a rotary lock on the right side. Top view.'

1/2

Image similar

Packaging type

Piece

Type

Line socket

Connection

Crimp

Soldering

Number of pins

Pins

3 + PE

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

143 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Packaging units

Number

Piece(s)

Total (€ 4.79 / piece)

€ 4.79

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

PG 7 cable gland, forward resistance ≤4Ohm

Packaging type: Piece

Pins: 3 + PE

Type: Line socket

Connection: Crimp
Soldering

Number of pins: 3

Total no. of pins: 3 + PE

Manufacturer part #: 932 186-100-1

Factory colour: Black

Content: 1 pc(s)

Standard: DIN

Connector type: Socket
Plug
right angle

Type: G 30 W 3 F

Leading contact (PE): Yes

Nominal voltage (details): 250 V

Nominal current (details): 10 A

Type: G 30 W 3 F

Connection: -

Operating voltage

Documents & Downloads

Datasheet

Datasheet 735151 Hirschmann 932 186-100-1 G 30 W 3 F Mains Voltage Connector Black Pins:3 + PE

User & Safety Instructions

User & Safety Instructions 735151 Hirschmann 932 186-100-1 G 30 W 3 F Mains Voltage Connector Black Pins:3 + PE

Description

Robust, compact series of right-angle connectors, dust/splash proof to IP65 standard (DIN VDE 0627/IEC61984) · Can be connected as desired, or using extruded cables of varying lengths · Solder and crimp contacts, but can also be connected to light barriers by ultrasonic welding · Very small dimensions, so they are perfect for the electrical connections for hydraulic or preumatic controls where space is very limited. Either solder or crimp connection. Contact box with cable gland and solder contacts.
