Hirschmann 935 980-161 CO ELST 3308 RV FM 805 M8 Socket For Front Panel Mounting Black
Product type
Sensor/actuator built-in connector
Connector type
Socket, built-in
Connector standard
Sensor connector
Connection side A
M8 socket, built-in
Connection side B
Cable, open end
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 9.99 / piece)
€ 11.99
-17 %
€ 9.99
incl. VAT
14-day return policy included
Technical specifications
- Type
CO ELST 3308 RV FM 805
- Product type
Sensor/actuator built-in connector
- Connector type
Socket, built-in
- Connector standard
Sensor connector
- Connection side A
M8 socket, built-in
- Connection side B
Cable, open end
- No. of pins
3
- Cable length
0.50 m
- Nominal voltage
60 V AC
60 V DC
- Nominal current
3 A
- Nominal current - rounded value
3 A
- Connector cross-section (max.)
0.25 mm²
- Connection
Open end cable
- Factory colour
Black
- Thread type connection side
M8
- Contact material
CuZn
- Contact surface
Gold plated
- Sensor/actuator connectivity fittings
M8 front panel fitting
IP67
- Min. temperature
-25 °C
- Max. temperature
+90 °C
- Seal type
Screw-on
- Manufacturer part #
935 980-161
- Content
1 pc(s)
- Type
Connector socket
- Nominal voltage (details)
60 V/AC/DC
- Nominal current (details)
3 A
- Contamination level
3
- Cross section
0.25 mm²
- Connection
-
- Contacts
gold-plated
- Temperature range
-25 - +90 °C
Documents & Downloads
Datasheet
Datasheet 735147 Hirschmann 935 980-161 CO ELST 3308 RV FM 805 M8 Socket For Front Panel Mounting Black
Description
For installing control circuits etc. in housings. Sockets complete with leads. Device plug complete with leads, snap-in or screw locking.
Scope of delivery
- Mounting nuts not included. Please order separately under 73 51 66-LA.
