HuiYuan 7206R1D-ESA-C LED flashing 5 mm 1.750 mcd 60 ° Bulk
EAN:
Part number:
Item no:
Packaging type
Bulk
Product type
LED flashing
Casing
5 mm
Type
THR
Light intensity I(V)
1.750 mcd
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
20
-
€ 0.15
60
13% = € 0.02
€ 0.13
100
20% = € 0.03
€ 0.12
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 20
Total (€ 0.15 / piece)
€ 3.00
plus VAT.
Technical specifications
- Packaging type
Bulk
- Product type
LED flashing
- Operating voltage
5 V
- Operating current
20 mA
- Casing
5 mm
- Type
THR
- Light intensity I(V)
1.750 mcd
- Wavelength
630 nm
- Radiation angle
60°
- Type (LEDs)
Diffused
- LED features
flashing
- Technology
AlGaInP
- Flash frequency
2 Hz
- Dim
(Ø) 5 mm
- Min. temperature
-40 °C
- Max. temperature
80 °C
- (Ø)
5 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2521079 HuiYuan 7206R1D-ESA-C LED flashing 5 mm 1.750 mcd 60 ° Bulk
User & Safety Instructions
User & Safety Instructions 2521079 HuiYuan 7206R1D-ESA-C LED flashing 5 mm 1.750 mcd 60 ° Bulk
Description
Hints
All standard LED chips require a current-limiting resistor/constant current power source.
