i-PRO I-PRO WV-X15700-V2LN Bullet-Kamera 4K AI WV-X15700-V2LN
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
I-PRO WV-X15700-V2LN security camera cartridge (form) IP security camera indoor & outdoor 3840 x 2160 pixels ceiling/wall
- IP security camera for indoors and outdoors
- CMOS 25.4 / 1.8 mm (1 / 1.8") 3840 x 2160 pixels
- Wired Ethernet/LAN
- Optical Zoom: 2x Digital Zoom: 12x
- Cartridge (shape) ceiling/wall
- White
- 440 g
Technical specifications
- Supported positioning: Inside & outside
- Form factor: Cartridge (shape)
- Tilt angle range 0 - 100°
- Supported audio formats: G.711,G.726
- Transfer type
Corded
- Width
170 mm
- Height
215 mm
- Depth
45 mm
- Weight
440 g
- Factory colour
White
- Display resolution
3840 x 2160 Pixel
- Type
IP-security camera
- 10/100/1000 Mbps ports
1 x
- Sensor type
CMOS
- UKCA
not relevant
- Operating temperature (T-T)
5 - 45 °C
- Ethernet LAN
yes
- Optical sensor size
25,4 / 1,8 mm (1 / 1.8")
- Number of sensors
1
- Pan range
180 - 180°
- Dynamic range
132 dB
- Firmware upgradeable
yes
- Zoom capability
yes
- Digital zoom
12 x
- Optical zoom
2 x
- Storage temperature (T-T)
-20 - 55 °C
- Built-in HDD
no
- Field of view (FOV) angle
104°
Documents & Downloads
Datasheet
Datasheet 3798788 i-PRO I-PRO WV-X15700-V2LN Bullet-Kamera 4K AI WV-X15700-V2LN
User & Safety Instructions
User & Safety Instructions 3798788 i-PRO I-PRO WV-X15700-V2LN Bullet-Kamera 4K AI WV-X15700-V2LN
Description
X Series Bullet Camera with high performance advanced AI 4K Bullet Camera. Up to 9 Edge AI-analysis-Apps. Compatible with the local KI learning APP Enables AI image analysis on non-AI cameras (with the AI Processing Relay APP). IP66, IP67 and IK10 certified. Integrated FIPS 140-2 Level 3 certified SecureElement (EdgeLock® SE050F NXP® Semiconductors). NDAA-compliant
This text is machine translated.
Scope of delivery
- I-PRO WV-X15700-V2LN BULLET CAMERA 4K AI OUTDOOR VANDAL
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
