Name: Impulse changeover switch Surface/flush mount Eltako ESR61M 1 maker, 1 maker 230 V DC, 230 V AC 10 A 2000 W 1 pc(s)
Brand: Eltako
SKU: 504612
Availability: InStock

Blue Eltako ESR61M relay with various connection terminals and technical specifications, suitable for 8-230V operating voltage.

Product type

Impulse changeover switch

Type

Multifunction

Functions

Impulse changeover switch

Operating voltage

230 V DC

230 V AC

Min. operating voltage

8 V DC

8 V AC

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

10 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 67.99 / piece)

€ 69.99

€ 67.99

incl. VAT

Only 10 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

Switching capacity (reference): light bulbs

Product type: Impulse changeover switch

Type: ESR61M

Type: Multifunction

Connection: Screws

Functions: Impulse changeover switch

Operating voltage: 230 V DC
230 V AC

Min. operating voltage: 8 V DC
8 V AC

Max. operating voltage: 230 V DC
230 V AC

Operating voltage: 8, 8 - 230, 230 V DC, V AC

Contact type: 1 maker
1 maker

Contact material: Copper

Switching voltage (max.): 250 V AC

Switching current (max.): 10 A

Max. switching capacity: 2000 W

Time range (min.): 0.1 s

Time range (max.): 14400 s

Width: 55 mm

Height: 45 mm

Depth: 32 mm

Dim: (W x H x D) 55 x 45 x 32 mm

Content: 1 pc(s)

RoHS-compliant: Yes

Factory colour: Multicolour

Mounting type: Surface/flush mount

Type: AP/UP-surge current switch 1 + 1 closer 10 A

Switching capacity: (Glow lamps) 2000 W

Switching voltage: 250 V AC

Switching current: 10 A

Type: ESR61M

Operating voltage: 8 - 230 V/UC

Weight: 100 g

: 10 A

: 18 mm

: 66 mm

: 58 mm

: 10 A

: 0.1-14400 s

: Screw connection

: 230-230 V

: 12-12 V

: Other

: AC

: 2

: Copper

: 230-230 V

: 8-8 V

: Thermoplastic

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 504612 Impulse changeover switch Surface/flush mount Eltako ESR61M 1 maker, 1 maker 230 V DC, 230 V AC 10 A 2000 W 1 pc(s)

User & Safety Instructions

User & Safety Instructions 504612 Impulse changeover switch Surface/flush mount Eltako ESR61M 1 maker, 1 maker 230 V DC, 230 V AC 10 A 2000 W 1 pc(s)

Conformity certificate

Conformity certificate 504612 Impulse changeover switch Surface/flush mount Eltako ESR61M 1 maker, 1 maker 230 V DC, 230 V AC 10 A 2000 W 1 pc(s)

Description

For flush and surface mounting No power consumption in standby. Control with 8 - 230 V/UC. The following functions can be selected by means of a rotary switch: Surge current switch or switching relay 2 closer · Surge current switch or switching relay 1 closer/1 opener · Series switch 1 + 1 closer switching sequence 1 · Switching relay (idling current relay) 2 opener · Series switch 1 + 1 closer switching sequence 2 · Switch-on wiping-relay 1 closer/1 opener (wiping time 1 s) · Group switch or group relay 1 + 1 closer. Switching sequences: 0/contact 1 (1-2)/contact 2 (3-4)/contacts 1 + 2 · 0/contact 1/contacts 1 + 2/contact 2 · 0/contact 1/0/contact 2 · Relay with changing closing contact.
