Intellinet 715140 19 inch Server rack cabinet power strip 1 U PG socket Black
EAN:
Part number:
Item no:
Number
Total (€ 34.45 / piece)
€ 34.45
plus VAT.
Highlights & Details
Intellinet 19" 7-way socket strip
- Sockets with increased contact protection by contact coversHorizontal 19" rack mounting on 1 HEAngled socket arrangementRugged aluminum construction.Earthing point for protection against external electrical voltage peaks
Technical specifications
- Product type
Server rack cabinet power strip
- Suitable for server rack cabinet (inch)
19 inch
- Rack unit
1 U
- Socket type
PG socket
- Outlets
7
- Voltage (max.)
230 V AC
- Dim
(W x H x D) 483 x 45 x 45 mm
- Amperage
16 A
4000 W
- Cable length
3 m
- Material
Aluminium
- Content
1 pc(s)
- Factory colour
Black
- Width
483 mm
- Height
45 mm
- Depth
45 mm
- Weight
1.04
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2753627 Intellinet 715140 19 inch Server rack cabinet power strip 1 U PG socket Black
Description
Power strip with 7 sockets and surge protection for horizontal rack mounting - power strip for up to seven network devicesMultiply a single power connector for network, telecommunications, security, AV or other electrical devices with this multiple socket strip from Intellinet NETWORK SOLUTIONS. In the arrangement angled to the right up to seven bulky plugs can be comfortably placed next to each other. The integrated 500 Joule/19,500-A surge protection for your devices, which protects against dangerous voltage peaks. The PDU uses only one height unit in 19-inch/483-mm racks. An illuminated power switch with protective flap allows you to switch the complete strip on or off as required.
This text is machine translated.
This text is machine translated.
Features
- Standards and certificatesCERoHSREACHIEC 60297IEC 60884Electrical detailsAC input 220.0 - 250.0 V, 50 - 60 HzMains voltage 230.0 VPlug type: Protective contact EU CEE 7/7 (type E/F), IEC 60884Socket type: EU CEE 7/7 (Type E/F); IEC 60884Maximum power: 4,000.0 WOverload protection: Maximum current 16.0 A.Overvoltage protection 500 Joule and 19,500-ampPhysical detailsDimensions (L x W x H) 45 x 483 x 45 mm1 HE rack mountingCable length 3 mCable type: H05VV-F 3G 1.5 mm²Socket angle 35°Net weight: 950 gGross weight: 1.05 kgAluminium casing
