Isabellenhütte VMK-R200-1.0 VMK-R200-1.0 SMD resistor 200 mΩ SMD 1206 1 W 1 % 20 ppm/K 1 pc(s)
Product type
SMD resistor
Type
1206
Resistance
200 mΩ
Power rating
1 W
Tolerance ±
1 %
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 10
Multiple: 10
Total (€ 3.29 / piece)
€ 32.90
incl. VAT
14-day return policy included
Highlights & Details
Resistance, metal foil, SMD 1206 (3216), 200 mΩ, 1 W, ±1%, VMK-R200-1.0
Our service for you
Technical specifications
- Type SMD 1206 (3216)
- Width: 1.6 mm
- Height: 0.4 mm
- Length: 3.05 mm.
- Weight: 0.00019 kg
- Output: 1 W
- max. temperature: 170 °C
- min Temperature -65 °C.
- Ohm resistance 200 mΩ
- Technology: Metal foil
- Temperature coefficient ±20 ppm/K
- Tolerance: ± 1 %
- Product type
SMD resistor
- Type
SMD
- Type
1206
- Resistance
200 mΩ
- Power rating
1 W
- Tolerance ±
1 %
- Temperature coefficient
20 ppm/K
- Length
3.05 mm
- Width
1.6 mm
- Height
0.4 mm
- Content
1 pc(s)
- Dim
(L x W x H) 3.05 x 1.6 x 0.4 mm
- RoHS-compliant
Yes
- Type
VMK-R200-1.0
Documents & Downloads
Datasheet
Datasheet 3208096 Isabellenhütte VMK-R200-1.0 VMK-R200-1.0 SMD resistor 200 mΩ SMD 1206 1 W 1 % 20 ppm/K 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3208096 Isabellenhütte VMK-R200-1.0 VMK-R200-1.0 SMD resistor 200 mΩ SMD 1206 1 W 1 % 20 ppm/K 1 pc(s)
Description
SMD precision resistors design 1206 1.0 Watt tolerance 1.0 % series ISA PLAN type Isabellenhütte VMK. Can be used as a measuring resistor in power supply units, power modules, frequency converters, control units and power hybrids
This text is machine translated.
This text is machine translated.
