Joyin JVR14N431K87YAW JVR14N431K87YAW Metal oxide varistor 430 V 1 pc(s) Tape
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 0.27243
50
9% = € 0.02
€ 0.24761
100
13% = € 0.03
€ 0.23770
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 0.27243 / piece)
€ 0.27
plus VAT.
Technical specifications
- ESD Packaging: No ESD
- Series JVR
- Delivery type: Belt
- Diameter, Resistance element 16.5 mm
- Diameter, connection wire 0.8 mm
- Surface temperature, max. 115 °C
- Resistance value_1: 0
- Max. OPERATING VOLTAGE (DC) 430 V DC
- Max. OPERATING VOLTAGE (AC) 275 V AC
- Varistor voltage (@1mA) 430 V
- Surge current 4,500 A.
- Energy absorption 132 J
- Response time, max. 25 ns
- Insulation resistance 1,000 MOhm
- APPROVALS UL, CSA, VDE
- Packaging type
Tape
- Vv
430 V
- Material
Metal
- Content
1 pc(s)
- Manufacturer part #
JVR14N431K87YAW
- Dim
(Ø x H) 16.5 mm x 46.0 mm
- (Ø)
16.5 mm
- Height
46.0 mm
- Width
6.1 mm
- Type
JVR14N431K87YAW
- CS
7.5 mm
- Peak current I(pp)
4.500 A
- RoHS-compliant
Yes
- UKCA
yes
- Product type
Metal oxide varistor
Documents & Downloads
Datasheet
Datasheet 3523402 Joyin JVR14N431K87YAW JVR14N431K87YAW Metal oxide varistor 430 V 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3523402 Joyin JVR14N431K87YAW JVR14N431K87YAW Metal oxide varistor 430 V 1 pc(s) Tape
Description
Application: For protection of electronic modules as voltage-dependent resistors (VDRs)
This text is machine translated.
This text is machine translated.
Features
- • Prevents the build-up of an overvoltage and avoids destruction
- • Absorbs the surge voltages
- • The maximum operating voltage must always be lower than the voltage of the varistor.
