Name: Joyin JVR14N471K87YAW JVR14N471K87YAW Metal oxide varistor 470 V 1 pc(s) Tape
Brand: Joyin
SKU: 3523404
Availability: InStock

Two gray ceramic disc capacitors attached to a strip, marked '1uN471K' and '9V'. The component has two leads for electrical connection.

Packaging type

Tape

Product type

Metal oxide varistor

V<sub>v</sub>

470 V

7.5 mm

(Ø)

16.5 mm

Datasheet (PDF)

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

109 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 3

Total (€ 0.33187 / piece)

€ 1.00

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

ESD Packaging: No ESD
Series JVR
Delivery type: Belt
Diameter, Resistance element 16.5 mm
Diameter, connection wire 0.8 mm
Surface temperature, max. 115 °C
Resistance value_1: 0
Max. OPERATING VOLTAGE (DC) 470 V DC
Max. OPERATING VOLTAGE (AC) 300 V AC
Varistor voltage (@1mA) 470 V
Surge current 4,500 A.
Energy absorption 140 J
Response time, max. 25 ns
Insulation resistance 1,000 MOhm
APPROVALS UL, CSA, VDE

Packaging type: Tape

Product type: Metal oxide varistor

Vv: 470 V

CS: 7.5 mm

Content: 1 pc(s)

(Ø): 16.5 mm

Height: 46.0 mm

Width: 6.4 mm

Manufacturer part #: JVR14N471K87YAW

Dim: (Ø x H) 16.5 mm x 46.0 mm

RoHS-compliant: Yes

Peak current I(pp): 4.500 A

Type: JVR14N471K87YAW

UKCA: yes

Variants(All information include VAT, plus shipping costs)

(Ø)

Height

Manufacturer part #

V<sub>v</sub>

Width

Joyin JVR05N390K65YAW JVR05N390K65YAW Metal oxide varistor 39 V 1 pc(s) Tape

Item no:3523387

Fast track dispatch on Thu 29 Oct

84 Piece(s)Conrad Electronic

7.5 mm

5 mm

35.0 mm

JVR05N390K65YAW

39 V

4.7 mm

Piece(s)

Minimum order quantity: 5

Multiple: 1

€ 0.12192^*

Joyin JVR05N391K65YAW JVR05N391K65YAW Metal oxide varistor 350 V 1 pc(s) Tape

Item no:3523388

Fast track dispatch on Thu 29 Oct

100 Piece(s)Conrad Electronic

7.5 mm

5 mm

35.0 mm

JVR05N391K65YAW

350 V

4.4 mm

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 0.0852^*

Joyin JVR07N101K65YAW JVR07N101K65YAW Metal oxide varistor 100 V 1 pc(s) #####Tape and Reel

Item no:3523389

Dispatches on Fri 30 Oct

7800 Piece(s)Conrad Electronic

9 mm

5 mm

37.0 mm

JVR07N101K65YAW

100 V

3.4 mm

Piece(s)

Minimum order quantity: 50

Multiple: 50

€ 0.07918^*

Joyin JVR07N201K65YAW JVR07N201K65YAW Metal oxide varistor 200 V 1 pc(s) Tape

Item no:3523390

Fast track dispatch on Thu 29 Oct

100 Piece(s)Conrad Electronic

9 mm

5 mm

37.0 mm

JVR07N201K65YAW

200 V

4.2 mm

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 0.08737^*

Joyin JVR07N220K65YAW JVR07N220K65YAW Metal oxide varistor 22 V 1 pc(s) Tape

Item no:3523391

Fast track dispatch on Thu 29 Oct

50 Piece(s)Conrad Electronic

9 mm

5 mm

37.0 mm

JVR07N220K65YAW

22 V

4.5 mm

Piece(s)

Minimum order quantity: 5

Multiple: 1

€ 0.126^*

Joyin JVR07N390K65YAW JVR07N390K65YAW Metal oxide varistor 39 V 1 pc(s) Tape

Item no:3523392

Fast track dispatch on Thu 29 Oct

100 Piece(s)Conrad Electronic

9 mm

5 mm

37.0 mm

JVR07N390K65YAW

39 V

4.7 mm

Piece(s)

Minimum order quantity: 5

Multiple: 1

€ 0.10873^*

Joyin JVR07N391K65YAW JVR07N391K65YAW Metal oxide varistor 350 V 1 pc(s) Tape

Item no:3523393

Fast track dispatch on Thu 29 Oct

79 Piece(s)Conrad Electronic

9 mm

5 mm

37.0 mm

JVR07N391K65YAW

350 V

5.3 mm

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 0.09624^*

Joyin JVR07N431K65YAW JVR07N431K65YAW Metal oxide varistor 430 V 1 pc(s) Tape

Item no:3523394

Fast track dispatch on Thu 29 Oct

80 Piece(s)Conrad Electronic

9 mm

5 mm

37.0 mm

JVR07N431K65YAW

430 V

5.5 mm

Piece(s)

Minimum order quantity: 5

Multiple: 1

€ 0.13569^*

Joyin JVR07N470K65YAW JVR07N470K65YAW Metal oxide varistor 47 V 1 pc(s) Tape

Item no:3523395

Fast track dispatch on Thu 29 Oct

100 Piece(s)Conrad Electronic

9 mm

5 mm

37.0 mm

JVR07N470K65YAW

47 V

5.0 mm

Piece(s)

Minimum order quantity: 5

Multiple: 1

€ 0.126^*

Joyin JVR07N471K65YAW JVR07N471K65YAW Metal oxide varistor 470 V 1 pc(s) #####Tape and Reel

Item no:3523396

Fast track dispatch on Thu 29 Oct

79 Piece(s)Conrad Electronic

9 mm

5 mm

37.0 mm

JVR07N471K65YAW

470 V

5.8 mm

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 0.08809^*

Documents & Downloads

Datasheet

Datasheet 3523404 Joyin JVR14N471K87YAW JVR14N471K87YAW Metal oxide varistor 470 V 1 pc(s) Tape

User & Safety Instructions

User & Safety Instructions 3523404 Joyin JVR14N471K87YAW JVR14N471K87YAW Metal oxide varistor 470 V 1 pc(s) Tape

Description

Application: For protection of electronic modules as voltage-dependent resistors (VDRs)

This text is machine translated.

Features

• Prevents the build-up of an overvoltage and avoids destruction
• Absorbs the surge voltages
• The maximum operating voltage must always be lower than the voltage of the varistor.

Description

Application: For protection of electronic modules as voltage-dependent resistors (VDRs)

This text is machine translated.

Features

• Prevents the build-up of an overvoltage and avoids destruction
• Absorbs the surge voltages
• The maximum operating voltage must always be lower than the voltage of the varistor.
