Isometric illustration of a dual seven-segment LED display module with two unlit digits on a rectangular circuit component.

Isometric illustration of a dual seven-segment LED display module with two unlit digits on a rectangular circuit component.

Packaging type

Bulk

Product type

Seven-segment display

Forward voltage U(F)

3.7 V

Shared connection

Anode

Width

48 mm

Datasheet (PDF)

Kingbright

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 11.99 / piece)

€ 11.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Single digit 7-segment LED display 57mm red

Large 1-digit 2.3-segment LED display: Digit height of 57 mm (7 inches)
High Leuchtkraft: Hyper-Red (AlGaInP technology) with diffuse white segment cover for optimal readability
Circuit design: Common anode (common anode) with decimal right point
Robust mounting: THT-design (through-hole technology) for through-hole assembly
Industrial structure: Low power consumption, high reliability and IC-compatible

Technical specifications

Chip-Material: AlGaInP
Grey front with white segments
Pin spacing (Spacing) 2.54 mm
Series distance 60.1 mm
Mounting THT
Operating temperature: -40 °C to +85 °C

Packaging type: Bulk

Product type: Seven-segment display

Type: SA23-12SURKWA

Forward voltage U(F): 3.7 V

Forward current I(F): 10 mA

Shared connection: Anode

Factory colour: Red

Width: 48 mm

Wavelength: 630 nm

Height: 70 mm

Light intensity I(V): 255 mcd

Digit height: 56.9 mm

No. of digits: 1

Dim: (L x W x H) 70 x 48 x 70 mm

Length: 70 mm

Depth: 12 mm

RoHS-compliant: Yes

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3825272 Kingbright Seven-segment display Red 56.9 mm 3.7 V No. of digits: 1 SA23-12SURKWA Bulk

User & Safety Instructions

User & Safety Instructions 3825272 Kingbright Seven-segment display Red 56.9 mm 3.7 V No. of digits: 1 SA23-12SURKWA Bulk

Description

Single-digit 7-segment LED display 57mm red to display numbers

This text is machine translated.

Scope of delivery

Kingbright SA23-12SURKWA 7-segment LED display

Description

Single-digit 7-segment LED display 57mm red to display numbers

This text is machine translated.

Scope of delivery

Kingbright SA23-12SURKWA 7-segment LED display
