KJ Electronics Electrolytic capacitor SMD 220 µF 35 V DC 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s) Tape
Packaging type
Tape
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
220 µF
Nominal voltage
35 V DC
Datasheet (PDF)
Part number:
Item no:
Number
Total (€ 0.93217 / piece)
€ 0.93
incl. VAT
14-day return policy included
Highlights & Details
KJ Electronics SMD electrolytic capacitor 220UF 35V 10x10.5 mm
- SMD electrolytic capacitors 16-50V 20% 105°C low ESR
- This text is machine translated.
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series: LZ
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Properties_1: • Low impedance
- Capacity 220 µF
- Capacity_1: 220
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.12
- Ripple current 670 mA
- Nominal voltage DC 35 V
- Lifetime_1: 2,000 h
- Packaging type
Tape
- Product type
Electrolytic capacitor
- Type
SMD
- Dim
(Ø x H) 10 mm x 10.5 mm
- Capacity (elec.)
220 µF
- Nominal voltage
35 V DC
- Tolerance ±
20 %
- Height
10.5 mm
- (Ø)
10 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
10 mm
- Length
10.5 mm
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Type
35LZ221MLC10X10,5EC
Documents & Downloads
Datasheet
Datasheet 3523767 KJ Electronics Electrolytic capacitor SMD 220 µF 35 V DC 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3523767 KJ Electronics Electrolytic capacitor SMD 220 µF 35 V DC 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s) Tape
