Name: Knipex 34 22 130 ESD ESD Round nose pliers Straight Chromium-vanadium ball bearing steel 135 mm
Brand: Knipex
SKU: 822136
Availability: InStock

A black and grey precision needle-nose pliers with the inscription '34 22 130 ESD' on the side, specifically designed for electrostatic discharge.

1/2

Fast track dispatch on Thu 15 Oct

14 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 46.99 / piece)

€ 46.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Precision electronics gripping pliers ESD

Electrostatic energy is discharged through the handles in a gradual and controlled manner
Protects components endangered by electrostatic discharge
For very precise assembly work, e.g. in electronics and fine mechanics
For gripping, holding and bending
Electrically discharging handles – dissipative
Smoothly ground gripping surfaces, edges finely rounded
Approx. 20 % lighter than conventional electronics pliers
Bolted joint and carefully manufactured joint surfaces for even, lowfriction movement throughout the entire opening range
Smooth-running double spring for a gentle and even opening
Ergonomically optimised multi-component handles
Forged from chrome vanadium ball-bearing steel
Burnished pliers
Polished head
Multi-component grips handles
DIN ISO 9655

Technical specifications

A 11.20 mm
B 22.70 mm
D 6.50 mm
E 1.60 mm
F 1.60 mm

Product type: Round nose pliers

Manufacturer part #: 34 22 130 ESD

Range of use: ESD

Length: 135 mm

Jaw shape: Straight

Material: Chromium-vanadium ball bearing steel

Material properties: burnished
polishing

DIN standard: DIN ISO 9655

Weight: 65 g

Type: 34 22 130 ESD

Standards: DIN ISO 9655

UKCA: not relevant

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 822136 Knipex 34 22 130 ESD ESD Round nose pliers Straight Chromium-vanadium ball bearing steel 135 mm

Description

Chrome steel ball bearings, forged, oil-hardened, burnished pliers, polished head, handles with multi-component grips.
Style 2: Half-round jaws

Features

Anti-glare finish
Lightweight
Carefully manufactured joint surfaces for even, low-friction movement throughout the entire opening range
Smooth, polished gripping surfaces; Edges carefully deburred
Low-friction dual spring for gentle and even opening
Electrically discharging design – dissipative
For gripping, holding and bending
Precision pliers for ultra-fine assembly work such as in electronics and precision mechanics
The range for the highest standards of performance and results
Ergonomic, two-coloured, multi-component ESD handle sleeves; Black/grey
Screwed joint: Precise, frictionless plier movement
