1/2
Image similar
LAPP 0027878/1000 Data transfer cable UNITRONIC® FD 25 x 0.34 mm² Grey 1000 m
Product type
Data transfer cable
No. of leads
25 x
Cross section (each core)
0.34 mm²
Cable features
Suitable for drag chains
Cable type
UNITRONIC® FD
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Data transfer cable
- Cable type
UNITRONIC® FD
- No. of leads
25 x
- Cross section (each core)
0.34 mm²
- Cross section
25 x 0.34 mm²
- Cable features
Suitable for drag chains
- Outside Ø
11 mm
- Factory colour
Grey
- Content
1000 m
- Bend radius (no. of ODs for fixed installation)
3
- Bend radius (no. of ODs for flexible installation)
5
- Sold per metre
No
- Halogen-free
No
- Manufacturer part #
0027878/1000
- Insulation material
Polyvinyl chloride
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (fixed installation)
80 °C
- Max. length sold by the metre
1000 m
- Type
UNITRONIC® FD 25x0,34
FALSE
0.34 mm²
Polyvinyl chloride (PVC)
Colour
According to IEC/EN 60332-1-2
Grey
Copper
Polyvinyl chloride (PVC)
-40-80 °C
25
FALSE
FALSE
11.9 mm
FALSE
Bare
59.5 mm
59.5 mm
35.7 mm
Other
Other
Round
FALSE
Documents & Downloads
Datasheet
Datasheet 3351053 LAPP 0027878/1000 Data transfer cable UNITRONIC® FD 25 x 0.34 mm² Grey 1000 m
User & Safety Instructions
User & Safety Instructions 3351053 LAPP 0027878/1000 Data transfer cable UNITRONIC® FD 25 x 0.34 mm² Grey 1000 m
Description
UNITRONIC ® FD 25x0.34 data cable low frequency; 25x0.34; wire color code: DIN 47100; PVC; drag chain
This text is machine translated.
This text is machine translated.
