LAPP 0041075/500 Ribbon cable 4 x 1.5 mm² 500 m
Product type
Ribbon cable
No. of leads
4 x
Cross section (each core)
1.5 mm²
Content
500 m
Cross section
4 x 1.5 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Ribbon cable
- No. of leads
4 x
- Cross section (each core)
1.5 mm²
- Cross section
4 x 1.5 mm²
- Content
500 m
- Nominal voltage
500 V
- Manufacturer part #
0041075/500
- Type
ÖLFLEX® CRANE CF 4G1,5
- Nominal voltage U0
300 V
1.5 mm²
Rubber
Colour
According to IEC/EN 60332-1-2
500 V
Black
Copper
Rubber
Class 6 = very flexible
-40-80 °C
300 V
4
18.5 mm
6.5 mm
TRUE
FALSE
Bare
Other
Other
Flat
TRUE
Documents & Downloads
Datasheet
Datasheet 3388455 LAPP 0041075/500 Ribbon cable 4 x 1.5 mm² 500 m
Datasheet 3388455 LAPP 0041075/500 Ribbon cable 4 x 1.5 mm² 500 m
User & Safety Instructions
User & Safety Instructions 3388455 LAPP 0041075/500 Ribbon cable 4 x 1.5 mm² 500 m
Description
ÖLFLEX® CRANE CF 4G1.5 flat cable; 41.5; U0/U: 300/500 V; rubber; wire identification: Colours; flexible
This text is machine translated.
This text is machine translated.
