LAPP 1030627/1000 Data transfer cable UNITRONIC® LiYCY (TP) 3 x 2 x 0.75 mm² Black 1000 m
Product type
Data transfer cable
No. of leads
6 x
Cross section (each core)
0.75 mm²
Cable features
Flexible
Cable type
UNITRONIC® LiYCY (TP)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Data transfer cable
- Cable type
UNITRONIC® LiYCY (TP)
- No. of leads
6 x
- Cross section (each core)
0.75 mm²
- Twisted pair cabling (part 1)
Yes (1)
- Cross section
3 x 2 x 0.75 mm²
- Cable features
Flexible
- Outside Ø
9 mm
- Factory colour
Black
- Content
1000 m
- Bend radius (no. of ODs for fixed installation)
56.4
- Bend radius (no. of ODs for flexible installation)
141
- Sold per metre
Yes
- Shielded
Yes
- Manufacturer part #
1030627/1000
- Insulation material
Polyvinyl chloride
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (fixed installation)
80 °C
- Max. length sold by the metre
1000 m
- Type
UNITRONIC® LiYCY (TP) 3x2x0,75 BK
TRUE
0.75 mm²
Polyvinyl chloride (PVC)
Black
Copper
Polyvinyl chloride (PVC)
-40-80 °C
9.4 mm
Bare
141.0 mm
56.4 mm
Other
Other
Round
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3351428 LAPP 1030627/1000 Data transfer cable UNITRONIC® LiYCY (TP) 3 x 2 x 0.75 mm² Black 1000 m
User & Safety Instructions
User & Safety Instructions 3351428 LAPP 1030627/1000 Data transfer cable UNITRONIC® LiYCY (TP) 3 x 2 x 0.75 mm² Black 1000 m
Description
UNITRONIC ® LiYCY (TP) 3x2x0.75 BK data cable low frequency; 3X2X0,75; Wire color code: DIN 47100, PVC, shielded; flexible
