Highlights & Details

MFT 1825 industrial system test device according to DIN VDE 0100/0105

Simple, color-coded function selection with 2 rotary switches
Large, backlit display for maximum user comfort
Small, compact housing, very light, only 1.2 kg, protection class IP 54.
2 and 3-wire loop resistance testing without FI/RCDAuslosung
Leakage current measurement with clamp-on ammeter
2- and 3-pin earthing measurement

Technical specifications

Low-ohm test with 200 mA DC
Test lead compensation
Acoustic continuity tester
Insulation test with 250 V, 500 V and 1000 V
FI/RCD testing type AC, A, S and F from 10 mA to 500 mA.
2 and 3-wire loop resistance testing without FI/RCDAuslosung
2-conductor loop resistance testing with a high test current
Line impedance
Rotating magnetic field indicator
Voltage and frequency measurements.

Product type: Electrical tester

: Manufacturer's standards (no certificate)

Reading category: CAT III 1000 V
CAT IV 300 V

Interfaces: none

Dim: (L x W x H) 95 x 270 x 130 mm

Weight: 1.2 kg

: IP54

Reading range (VDE): Insulation resistance
Leakage current
Differential current
Touch voltage
Voltage

DIN standard: DIN IEC 60364
DIN EN 50110

Display type: Digital (LCD)

Reading range

Width: 270 mm

Height: 130 mm

Length: 95 mm

Test procedure: manual

Voltage supply: Battery

Memory: No

Type: MFT1825-SC-DE/NL/EN

VDE standard: 0100
0105

Features: RCD/FI testing

Display (details): Dual LCD display (3 1/2 digits) with symbols, additional analogue display

Reading category: CAT III 1000 V / CAT IV 300 V

Standards: Measurements according to DIN VDE 0100-600, DIN VDE 0105-100

Weight, information: incl. batteries

Documents & Downloads

Datasheet

Datasheet 106265 Megger MFT1825-SC-DE/NL/EN Electrical tester VDE standard 0100, 0105

User & Safety Instructions

User & Safety Instructions 106265 Megger MFT1825-SC-DE/NL/EN Electrical tester VDE standard 0100, 0105

Information

Information 106265 Megger MFT1825-SC-DE/NL/EN Electrical tester VDE standard 0100, 0105

Description

The System Test Equipment MFT 1800-series are multi-functional installation tester of the latest generation and include all the necessary test functions for the acceptance of electrical equipment according to DIN VDE 0100/0105. Outstanding are the easy to use rotary switches, with which you can set all measurement functions comfortably and securely. No complicated menu navigation. Can also be used with thick safety gloves. Two test buttons on the measuring device allow a two-sided operation. The installation testers of the MFT 1800 Series full input protection in all function and show security warnings for dangerous voltages.

This text is machine translated.

Features

Double-sided operation by means of duplicate test
Remote control by means of probe tip with start button
Autostart function
Insulation measurement with limit value display and adjustable continuous measurement
Use NiMH rechargeable batteries is possible.
