Image similar
Mentor LED wired Green 3 mm 20 mcd 40 ° 20 mA 2.1 V
Product type
LED wired
Forward voltage U(F)
2.1 V
Forward current I(F)
20 mA
Casing
3 mm
Type
THT
Datasheet (PDF)
Part number:
Item no:
Number
Total (€ 0.96 / piece)
€ 0.96
incl. VAT
14-day return policy included
Highlights & Details
Single LED display
- THT
- Connection wire
- Horizontal alignment
Technical specifications
- Product type
LED wired
- Type
Single LED display
- Factory colour
Green
- Forward voltage U(F)
2.1 V
- Forward current I(F)
20 mA
- Operating voltage
2.1 V
- Operating current
20 mA
- Casing
3 mm
- Type
THT
- Light intensity I(V)
20 mcd
- Wavelength
568 nm
- Radiation angle
40°
- Dim
(Ø x H) 3 mm x 9.5 mm
- Min. temperature
-40 °C
- Max. temperature
85 °C
- Length
24.8 mm
- Width
5 mm
- Height
9.5 mm
- (Ø)
3 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3788292 Mentor LED wired Green 3 mm 20 mcd 40 ° 20 mA 2.1 V
User & Safety Instructions
User & Safety Instructions 3788292 Mentor LED wired Green 3 mm 20 mcd 40 ° 20 mA 2.1 V
Description
The development of these components was based on the know-how of MENTOR, which has been acquired over decades, as a developer and supplier of components for industrial electronics. They can be used anywhere where light signals are and must attract attention to functions or operating conditions. The variety of components ranges from single and multiple displays and strips in various designs to lamp holders.
This text is machine translated.
This text is machine translated.
Hints
All standard LED chips require a current-limiting resistor/constant current power source.
