Microchip Technology ATTINY13-20PU Embedded microcontroller PDIP 8 8-Bit 20 MHz I/O number 6
EAN:
Part number:
Item no:
Product type
Embedded microcontroller
Clock speed
20 MHz
Series
AVR® ATtiny
Type
ATTINY13-20PU
Manufacturer
Microchip Technology
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.61
5
7% = € 0.30
€ 4.31
10
9% = € 0.42
€ 4.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.61 / piece)
€ 4.61
plus VAT.
Technical specifications
- Type
ATTINY13-20PU
- Product type
Embedded microcontroller
- Manufacturer
Microchip Technology
- Manuf. code
MCP
- Enclosure
PDIP 8
- Clock speed
20 MHz
- Series
AVR® ATtiny
- Core size
8-Bit
- Processor core
AVR
- Oscillator type
Internal
- Peripherals
Brown-out Detect/Reset
POR
PWM
WDT
- I/O number
6
- Program memory type
FLASH
- Supply voltage (max.)
5.5 V
- Supply voltage (min.)
2.7 V
- Operating temperature (max.)
+85 °C
- Operating temperature (min.)
-40 °C
- Data converter (embedded microcontroller)
A/D 4x10b
- EEPROM size
64 x 8
- Program memory size
1 KB (512 x 16)
- RAM size
64 x 8
Documents & Downloads
Datasheet
Datasheet 154139 Microchip Technology ATTINY13-20PU Embedded microcontroller PDIP 8 8-Bit 20 MHz I/O number 6
User & Safety Instructions
User & Safety Instructions 154139 Microchip Technology ATTINY13-20PU Embedded microcontroller PDIP 8 8-Bit 20 MHz I/O number 6
Description
The ATTINY13-20PU belongs to the AVR microcontroller family by Atmel, which is based on an entirely new architecture. It is a real RISC architecture in which the quartz frequency is not internally divided, ie a 10 MHz quartz crystal gives an order throughput of 10 million orders per second. The relatively low oscillation frequency means that power consumption remains very low. All AVRs have flash programme memories, EEPROM data memories and can be programmed in the system. Programming of the OnChip flash and EEPROM memory functions solely by sendind commands. No programming voltage is required. The AVRs have 32 equivalent registers that can be used in parallel. The command set comprises 120 instructions allowing you to write extremely efficient programmes.
