Mobotix Mx-D16B-F-6D6N079 LAN IP CCTV camera 3072 x 2048 p
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
LAN IP-Dome camera;3072 x 2048 p;Mobotix;Mx-D16B-F-6D6N079Outdoors
- Resolution 6 MP
- With two B 079 lenses
- 45° Day/Night
- This text is machine translated.
Technical specifications
- Operating temperature: -40 to + 60 °C.
- Video formats: MxPEG/MJPEG/H.264
- Max. Image size (dual screen with both image sensors): 2 x 6 MP (6144 x 2048)
- Product type
CCTV camera
- Series
MOBOTIX D16
- CCTV features
Saves footage on SD card
2-way communication
Speaker
Microphone
ONVIF support
PoE IEEE 802.3af
Optical zoom
- Camera type
Dome camera
- Resolution (max.)
3072 x 2048 p
- Sensor size
14.11 mm (1/1.8")
- Sensor type
CMOS
Manufacturer-specific
- Max. viewing angle hor.
45°
- Vertical viewing angle
34°
- App compatibility
Yes
- Transfer type
LAN
- Light sensitivity (+ IR)
0.001 lx
- Used at
Outdoors
- Type
microSD card (up to 4 GB)
- Height
108 mm
- (Ø)
205 mm
- Dim
(Ø x H) 205 mm x 108 mm
- Weight
640 g
- Factory colour
White
IK10
IP54
- Signal standard
IP
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1894015 Mobotix Mx-D16B-F-6D6N079 LAN IP CCTV camera 3072 x 2048 p
User & Safety Instructions
User & Safety Instructions 1894015 Mobotix Mx-D16B-F-6D6N079 LAN IP CCTV camera 3072 x 2048 p
Description
A camera. Two Views.
Two lenses, two Hifi Res-Bildsensoren, internal microSD memory and a 12 megapixel large double image of the D16B dual dome to the efficient security solution: with only one camera secure also two different areas - completely without vulnerable mechanics.
This text is machine translated.
Two lenses, two Hifi Res-Bildsensoren, internal microSD memory and a 12 megapixel large double image of the D16B dual dome to the efficient security solution: with only one camera secure also two different areas - completely without vulnerable mechanics.
This text is machine translated.
Features
- The mx6 system platform 2. Generation, with MxBus
- Multi-streaming
- Digital zoom with panning (vPTZ)
- Recording on internal 4 GB MicroSD card (standard)
- Built-in microphone and speaker
- Vibration, temperature and PIR sensor integrated
- For ceiling or wall mount suitable
- Simple installation even in building corners and masts
- Mobile MOBOTIX App, MxManagementCenter.
Scope of delivery
- Camera with two B 079 lenses
- Fixings
- Ethernet patch cable 0.5 m
- Kuzanleitung.
