Mobotix Mx-p26B-6D016 LAN IP CCTV camera 3072 x 2048 p
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
LAN IP-Compact camera;3072 x 2048 p;Mobotix;Mx-p26B-6D016Indoors
- Resolution 6 MP
- With B016 Lens
- 180° Day
Technical specifications
- Video formats: MxPEG/MJPEG/H.264
- Operating temperature: -0 to + 40 °C.
- Product type
CCTV camera
- CCTV features
Saves footage on SD card
ONVIF support
PoE IEEE 802.3af
Fish eye lens
- Camera type
Compact camera
- Resolution (max.)
3072 x 2048 p
- Sensor size
14.11 mm (1/1.8")
- Sensor type
CMOS
- Max. viewing angle hor.
180°
- Vertical viewing angle
180°
- App compatibility
Yes
- Transfer type
LAN
- Used at
Indoors
- Type
microSD card (up to 4 GB)
- Height
89 mm
- (Ø)
120 mm
- Dim
(Ø x H) 120 mm x 89 mm
- Weight
270 g
- Factory colour
White
IK06
IP20
- Signal standard
IP
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1894049 Mobotix Mx-p26B-6D016 LAN IP CCTV camera 3072 x 2048 p
User & Safety Instructions
User & Safety Instructions 1894049 Mobotix Mx-p26B-6D016 LAN IP CCTV camera 3072 x 2048 p
Description
Flexible and compact. Depends on your wishes.
Equipped with light sensitive 6-megapixel moonlight-Sensor and manually ausrichtbarem lens (15° distance tele up to 180° Hemispheric), the p26B with any interior situation is ready. The system provides with competitive prices, the complete MOBOTIX functions and the Free Software MxManagementCenter one of the most attractive indoor security solutions on the market. With the available as accessories MxIOBoard IC receives the camera is also an mx bus connection, two inputs and two 12-VAusgange.
This text is machine translated.
Equipped with light sensitive 6-megapixel moonlight-Sensor and manually ausrichtbarem lens (15° distance tele up to 180° Hemispheric), the p26B with any interior situation is ready. The system provides with competitive prices, the complete MOBOTIX functions and the Free Software MxManagementCenter one of the most attractive indoor security solutions on the market. With the available as accessories MxIOBoard IC receives the camera is also an mx bus connection, two inputs and two 12-VAusgange.
This text is machine translated.
Features
- The mx6 system platform 2. Generation, with MxBus
- Recording on internal 4 GB microSD card (standard)
- For the ceiling installation, Aufputz-Set optional
- Standard with MxAnalytics video analysis tools (heat maps, number of corridors)
- Multi-streaming
- Digital zoom with panning (vPTZ)
- Vibration and built-in temperature sensor
- Mobile MOBOTIX App, MxManagementCenter.
Scope of delivery
- Camera with B016 Lens
- Fixings
- Ethernet patch cable 0.5 m
- Quick guide.
