Molex Built-in pin strip (standard) Total number of pins 4 Contact spacing: 10 mm 428194213 1 pc(s) Tray
EAN:
Part number:
Item no:
Product type
Built-in pin strip (standard)
No. of rows
1
CS
10 mm
Total number of pins
4
Packaging type
Tray
Datasheet (PDF)
Number
Minimum order quantity: 15
Multiple: 1
Total (€ 7.03 / piece)
€ 105.45
incl. VAT
14-day return policy included
Highlights & Details
MINIFIT SR
- Content: 1 pc(s)
- No. of rows: 1
- Total number of pins: 4
Our service for you
Technical specifications
- Please review product datasheet for further information.
- Packaging type
Tray
- Product type
Built-in pin strip (standard)
- No. of rows
1
- Features
+ locking mechanism
- CS
10 mm
- Pins per row
4
- Total number of pins
4
- Nominal current
50 A
- Nominal current - rounded value
50 A
- Content
1 pc(s)
- Connection
Soldering
- Coating thickness (PCB side)
2.54 µm
- Connector coating thickness
0.762 µm
- Case material
High temperature resistant thermoplastic
- Manufacturer part #
428194213
- Factory colour
Black
- Contact material
Brass
- Board contact surface
Tin
- Connector contact surface
Gold
- Nominal voltage
600 V
- RoHS-compliant
Yes
- Connector orientation
Perpendicular (to the PCB)
- Max. temperature
+105 °C
- Min. temperature
-40 °C
- Type
Molex MOL Power & Signal Sol.
- Engineering Part No
42819-4213
- Engineering Series Name
MINIFIT SR VERT HDR
- Engineering Series No
42819
Documents & Downloads
Datasheet
Datasheet 2448491 Molex Built-in pin strip (standard) Total number of pins 4 Contact spacing: 10 mm 428194213 1 pc(s) Tray
User & Safety Instructions
User & Safety Instructions 2448491 Molex Built-in pin strip (standard) Total number of pins 4 Contact spacing: 10 mm 428194213 1 pc(s) Tray
Circuit diagramm
Circuit diagramm 2448491 Molex Built-in pin strip (standard) Total number of pins 4 Contact spacing: 10 mm 428194213 1 pc(s) Tray
Description
10.00mm Pitch Mini-Fit Sr. Header, Single Row, Vertical, 1.57mm PCB Thickness, 0.76µm Gold (Au) Selective Plating, 4 Circuits
