Molex Built-in pin strip (standard) Total number of pins 4 Contact spacing: 3 mm 444320401 1 pc(s) Tray
EAN:
Part number:
Item no:
Product type
Built-in pin strip (standard)
No. of rows
2
CS
3 mm
Total number of pins
4
Packaging type
Tray
Datasheet (PDF)
Number
Minimum order quantity: 144
Multiple: 144
Total (€ 2.23 / piece)
€ 2.39
-7 %
€ 321.12
incl. VAT
14-day return policy included
Highlights & Details
Micro Fit
- Content: 1 pc(s)
- No. of rows: 2
- Total number of pins: 4
Our service for you
Technical specifications
- Please review product datasheet for further information.
- Packaging type
Tray
- Product type
Built-in pin strip (standard)
- No. of rows
2
- Connector system
wire-to-board
- Features
+ anti-twist safeguard
- CS
3 mm
- Pins per row
2
- Total number of pins
4
- Nominal current
8.5 A
- Nominal current - rounded value
8.5 A
- Content
1 pc(s)
- Connection
Soldering
- Connection angle
90°
- Coating thickness (PCB side)
5.08 µm
- Connector coating thickness
5.08 µm
- Actuation direction
Perpendicular (to the PCB)
- Case material
High temperature resistant thermoplastic
- Manufacturer part #
444320401
- Factory colour
Black
- Contact material
Brass
- Board contact surface
Tin
- Connector contact surface
Tin
- Nominal voltage
250 V DC/AC
- RoHS-compliant
Yes
- Connector orientation
Perpendicular (to the PCB)
- Max. temperature
+105 °C
- Min. temperature
-40 °C
- Type
Molex MOL Power & Signal Sol.
- Engineering Part No
44432-0401
- Engineering Series Name
MICROFIT 3.0 BMI VHD
- Engineering Series No
44432
Documents & Downloads
Datasheet
Datasheet 2448816 Molex Built-in pin strip (standard) Total number of pins 4 Contact spacing: 3 mm 444320401 1 pc(s) Tray
User & Safety Instructions
User & Safety Instructions 2448816 Molex Built-in pin strip (standard) Total number of pins 4 Contact spacing: 3 mm 444320401 1 pc(s) Tray
Circuit diagramm
Circuit diagramm 2448816 Molex Built-in pin strip (standard) Total number of pins 4 Contact spacing: 3 mm 444320401 1 pc(s) Tray
Description
Micro-Fit BMI Header, Dual Row, Vertical, with PCB Polarizing Peg, 4 Circuits, Tin (Sn) Plating, Kinked Tails
