Name: Molex Built-in SIL socket (standard) Total number of pins 4 Contact spacing: 4.2 mm 1724480004 1 pc(s) Piece
Brand: Molex
SKU: 2447468
Availability: InStock

A square, black connector with four socket openings and two metal pins. Suitable for electronic connections.

Product type

Built-in SIL socket (standard)

No. of rows

4.2 mm

Total number of pins

Packaging type

Piece

Datasheet (PDF)

Dispatches on Mon 19 Oct

4980 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 165

Multiple: 165

Total (€ 0.91 / piece)

€ 1.19

-24 %

€ 150.15

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

MINI FIT

Content: 1 pc(s)
No. of rows: 2
Total number of pins: 4

Our service for you

Technical specifications

Please review product datasheet for further information.

Packaging type: Piece

Product type: Built-in SIL socket (standard)

No. of rows: 2

Features: + locking mechanism

CS: 4.2 mm

Pins per row: 2

Total number of pins: 4

Nominal current: 13 A

Nominal current - rounded value: 13 A

Content: 1 pc(s)

Connection: Soldering

Connection angle: 90°

Coating thickness (PCB side): 0.762 µm

Connector coating thickness: 0.762 µm

Actuation direction: Parallel (to the PCB)

Case material: Nylon (NL)

Manufacturer part #: 1724480004

Factory colour: Black

Contact material: Brass

Board contact surface: Tin plated

Connector contact surface: Tin

Nominal voltage: 600 V

RoHS-compliant: Yes

Connector orientation: Parallel (to the PCB)

Max. temperature: +105 °C

Min. temperature: -40 °C

Type: Molex MOL Power & Signal Sol.

Engineering Part No: 172448-0004

Engineering Series Name: MiniFit Jr Ra Header

Engineering Series No: 172448

Documents & Downloads

Datasheet

Datasheet 2447468 Molex Built-in SIL socket (standard) Total number of pins 4 Contact spacing: 4.2 mm 1724480004 1 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 2447468 Molex Built-in SIL socket (standard) Total number of pins 4 Contact spacing: 4.2 mm 1724480004 1 pc(s) Piece

Circuit diagramm

Circuit diagramm 2447468 Molex Built-in SIL socket (standard) Total number of pins 4 Contact spacing: 4.2 mm 1724480004 1 pc(s) Piece

Description

Mini-Fit Jr. Header, Dual Row, Right-Angle, with Snap-in Plastic Peg PCB Lock, 4 Circuits, PA Polyamide Nylon 6/6 94V-2, Tin (Sn) Plating, Glow-Wire Capable
